12 Cylinder Capacity High Pressure Gas Cylinder Cluster Frame

We manufacture a superior and more durable frame for commercial and industrial use that allows the distributor to transport directly to the job site. Our frames are designed for forklifts top, bottom and overhead lifting gear.

Safe storage is a must on the job sites. So we use a double turn buckle and front bars to secure, protect cylinders and provide structural integrity.

Cluster Frame Description:

  • Capacity 12 - 200/300 size cylinders in a lockable position
  • Weight Certification
  • 100% Galvanized w/ optional black powder coating
  • Manifold bracket
  • Fully welded construction
  • Weld on ID Mounting Plate

Structural Materials Include:

  • ¼” Plate top & bottom
  • C 2 x 1 x 1/8”
  • C 3 x 4.1#
  • C 4 x 5.4#
  • Rec. Tube 6 x 3 x 3/16”
  • Four 3/8” Plate Lugs
  • Center Lift 1” Round Bar
  • (2) Front Bars
  • (4) Double Turn Buckle

Since 2003 these frame have been field tested to the satisfaction of the customers. If there is any questions or any way we can be of service please let us know.
